The AS series extractors are designed for the suction of offcuts and production waste deriving from production cycles and packaging machinery. The vacuumed scraps are contained and compacted in a nylon bag, which filters out any dust and allows waste to be removed quickly and easily. Built-in silencer and window for monitoring the fullness of the bag.
The AS 70's horizontal construction makes it extremely stable and the enlarged container can hold up to 200 litres of production waste.
ADVANTAGES
- Side channel blower motor , powerful and silent, totally maintenance free, suitable for continuous duty
- Complete steel construction
- Low noise level
- Compact and mobile
- Conceived for packaging lines scraps and wastes suction
- Tank provided with large capacity nylon filtering bag
- Full customization for specific needs
- Easy to handle
- Suitable for continuous use 24/7
DATA SHEET
| Index | Unit | AS 70 |
|---|
| Voltage | V - Hz | 400 - 50 |
| Power | kW | 5,5 |
| Electrical protection | IP | 65 |
| Max water lift | mmH₂O | 3.600 |
| Max air flow | m³/h | 530 |
| Suction inlet | mm | 80 |
| Noise level (EN ISO 3744) | dB(A) | 71 |
| Continuous water lift | mmH₂O | 3.000 |
| Filter Type | | Bag |
| Material - Efficiency | IEC 60335-2-69 | Nylon - L |
| Capacity | l | 210 |
| Dimensions | cm | 63x100x125h |
| Weight | kg | 125 |
