Equipped with double ATEX certification and antistatic filters, this INERT model offers the ideal solution for the efficient and safe removal of conductive dust and gases in areas at high risk of explosion.
The inert oil inside the container with inert system allows to neutralize the dust and gases as soon as they are vacuumed.
Power is provided by the powerful Venturi unit with 7 or 14 nozzles, ensuring optimal performance with a remarkable ratio between air consumption and efficiency, all without the need for routine maintenance.
ADVANTAGES
- Heavy duty steel construction
- Compressed air supply through a double Venturi suction unit
- Inert liquid bath system for the safe discharge of explosive and conductive metal dust
- Easily removable container for safe disposal of collected material
- Prevents the build-up of the explosive atmosphere inside the vacuum
- High efficiency filtration
- Powerful suction thanks to a multi-nozzle venturi unit
- Compliant with EN 17348: WET TYPE
DATA SHEET
| Index | Unit | 452 AIREX 1/2D-2/2G |
|---|
| Air supply | nlt / min | 729 - 1.458 |
| Air supply pressure | bar | 6 |
| Ø Air supply hose | mm | 12 |
| Max water lift | mmH₂O | 3.700 |
| Max air flow | m³/h | 150 - 300 |
| Suction inlet | mm | 50 |
| Noise level (EN ISO 3744) | dB(A) | 68 |
| Marking | | II 1/2D Ex h IIIC T85° Da/Db - II 2/2G Ex h IIB T6 Gb/Gb |
| Atex zones | | 1/2D (20 int/21 ext) 2/2G (1 int/1 ext) |
| Surface - Diameter | cm²-mm | 20.000 - 420 |
| Material - Efficiency | IEC 60335-2-69 | Ant Polyester - M PTFE |
| Cleaning system | | Manual |
| Secondary filter | | HEPA |
| Dimensions | cm | 70x55x127h |
| Weight | kg | 50 |
